ED Rod Type
Straight rod SiC element for common industrial furnace applications.
- OD / hot zone / cold end
- Replacement review
SiC HEATING ELEMENTS
SiC Heating Elements for High-Temperature Industrial Furnaces
Silicon carbide heating element solutions with factory-resource-backed technical communication for selection, replacement and custom requirements.
SILICON CARBIDE MATERIAL
SiC Heating Element Support
SiC heating elements are used for industrial furnace heating applications where product type, geometry and furnace conditions need to be confirmed before production.
- Available directions: ED, DB, U, W, SC, SCR and UX types.
- Specification review: OD, hot zone, cold end, overall length, resistance, voltage and power.
- Project support: old element replacement, resistance grouping communication and application review.
ED / DB / U / W / SC TYPES
SiC Product Type Entry
Each type page explains structure, key parameters and applications to help customers prepare review data.
DB Dumbbell Type
Dumbbell type SiC element with different hot and cold end geometry.
- D1 / D2 confirmation
- Drawing review
U / W Type
U and W type SiC elements for specific furnace layouts.
- Bridge spacing
- Installation structure
SC / SCR / UX Type
Special SiC types for threaded, slot or custom connection requirements.
- Accessory matching
- Custom support
SiC TECHNICAL PARAMETERS
Reference Parameters to Prepare
Prepare geometry, electrical and furnace data before submitting for technical review.
| Field | What to Prepare | Why It Matters | Action |
|---|---|---|---|
| Geometry | OD, hot zone, cold end, overall length | Replacement size and furnace installation confirmation | View Tables |
| Electrical | Voltage, power, resistance | Electrical matching and grouping communication | Submit Data |
| Furnace | Temperature, atmosphere, application | Application-based selection communication | Solutions |
REQUEST SiC TECHNICAL REVIEW
Need help replacing or confirming SiC elements?
Upload old element photos, drawings and furnace parameters for review.
